Grupp F I.
Ur kapten F A Spaks katalog 1888: Kanonen är ett enkelt eldrör av metall. Druvan är bladknoppsformig.
BOTTENSTYCKET. Fängpannan är musselformig med uppstående kanter, omedelbart framför kammarsiraterna. På ömse sidor om fäng- pannan finns en S-formigt svängd bladranka (relief). Mellan kammarbandet och bakfrisen finns Gripenhielms vapensköld (enligt Spak; relief) samt under densamma inskriptionen (plattrelief): NILS: GRIPRENHIELM. FRIHERRE. LANDZHÖFDIN ÖFWER STORA KOPARBER. LÄHN 1703. (Obs! De båda sista bokstäverna i LANDZHÖFDIN är nästan utnötta men torde vara IN). Omedelbart bakom bakfrisen finns en bård (i relief) av utbredd akantusblad (bakfrisen utgör baslinje). Bården saknas på kanonens undersida, på ca 1/3 av dess omkrets.
TAPPSTYCKET. Tapparnas fria ända är ornerad i stiliserat blomm- önster.
LÅNGA FÄLTET. Omedelbart framför framfrisen finns en likadan bladbård som bakom bakfrisen. Denna går dock runt hela kanonen. Trumfen trumpetförstärkt med korn och omedelbart bakom detta en liten rund, skålformig fördjupning.
Mått:
Eldrörets längd är 105,5 cm.
Bottenstycket
Bottenstyckets största diameter 14 cm, Bottenstyckets minsta diameter 13,5 cm, Kammarsiraternas bredd 4 cm, Kammarsiraternas bandsläge 8 cm, Kammarsiraternas bandsbredd 1,5 cm.
Tappstycket
Tappstyckets största diameter 13 cm, Tappstyckets minsta diameter 13 cm, B. frisläge 31,5 cm, B. frisbredd 2 cm, Delfinens läge 37cm, Delfinens längd 10 cm, Delfinens höjd 5 cm, Tappläge I 43 cm, Tapplängd 4 cm, Tappdiameter 4,5 cm.
Långa fältet
Långa fältets största diameter ca 12 cm, Långa fältets minsta diameter ca 9,5 cm, Fr. frisläge 47,5 cm, Fr. frisbredd 2 cm, Halsbandsläge 95 cm, Halsbandsbredd 1,5 cm, Trumfens största diameter 12 cm
