Nominalkaliber 20,04 mm. Verklig kaliber 19,7 mm.
PIPAN är ovanligt väl arbetad. Kammarstycket är 21,8 cm långt och åttkantigt, utom längst fram, där det på en längd av 2,1 cm är sextonkantigt. Framtill begränsas det av ett par insvarvade ränder. Ett par dylika går runt det långa fältet 4 och en halv cm de sistnämnda och en halv cm längre framför finns ännu ett par dylika ränder. Ett knappformigt järnkorn sitter 2,3 cm bakom mynningen och ett långt ståndsikte längst fram på svansskruvsstjärten. Tre häften, nedifrån insatt korsskruv. På kammarstyckets översida kronstämpel med bokstäverna PO samt årtalet 1688. På undersidan en kraftigt inslagen stämpel med mongram, sannolikt med bokstäverna V O M.
LÅS med svart kullrigt bleck, baktill utdraget i en spets. Pannskruven går inifrån, fängpannnan har stort nästan halvklotformigt fängpannetåg och baktill stor eldskärm, pannlocket har runt, nedåtböjt, framåt tjockare handtag. På bleckets utsida en stämpel med monogram av bokstäverna P L. Tre låsskruvar.
STOCK av svart al, med rätt starkt krökt kolv, dock ej så kraftigt krökt som på AM 4065, plan kolvrygg, avrundad kolvände, kräva. Baktill på kolvens vänstra sida är siffran 5 inslagen. På kolvhalsens högra sida litet bakom svansskuvsstjärten och ovanför låset är bokstäverna B S inbrända. På kolvens högra sida sitter en mässingsplåt med S G F 9. = Stockholms gevärsförråd 19. Vid låset är piprännans högra kant skadad och hålet för mellanhäftet är fruktansvärt utvidgat.
BESLAG av järnplåt. Bakplåten är fäst med stift, Varbygeln är fäst med två stift, framtill med korsskruven och framför den främre änden utbildad till en ögla. I laddstocksrännan finns två släta rörkor. Krävbeslaget är 4 och näsblecket 3,4 cm brett. Den främre rembygeln är U-formig, och dess skruv går genom krävan och krävbeslaget. Dess bakre överkant är utbildad till en i öglan på varbygelns framände inpassad ögla.
LADDSTOCKEN är av trä och har på smaländen ett 7,5 cm långt, med gängat hål för kratsen försett järnbeslag.
